How to Archive WhatsApp Chat History to a Database

When you pair a new device, WhatsApp pushes a copy of your recent chat history to it. whatsmeow-node forwards that data as history_sync events, with each message in the same { info, message } shape as a live message event. This means one function can archive both old and new messages. This guide stores everything in SQLite with better-sqlite3.

Prerequisites​

  • Node.js 22+ and whatsmeow-node installed (Installation). The current better-sqlite3 (13.x) requires Node 22; on Node 20, install better-sqlite3@12 instead.
  • better-sqlite3 and qrcode-terminal: npm install better-sqlite3 qrcode-terminal (plus @types/better-sqlite3 and @types/qrcode-terminal for TypeScript)
  • A phone with WhatsApp that you can pair (How to Pair). To receive the initial history, the archiver has to be running when you pair. See Step 6.

The history_sync Event​

client.on("history_sync", ({ type, chunkOrder, progress, conversations }) => {
  // type:          "INITIAL_BOOTSTRAP", "RECENT", "FULL", "PUSH_NAME", "ON_DEMAND", ...
  // chunkOrder:    order of this chunk within the sync
  // progress:      sync progress in percent (0 when the sync type doesn't report it)
  // conversations: [{ id, name, unreadCount, messages: [{ info, message }] }]
});

Each entry in conversations[].messages has an info (id, chat, sender, isFromMe, isGroup, timestamp, pushName) and a message object with proto field names, like live messages. A large account's history comes in many chunks spread over several minutes, so you should store each chunk as it arrives.

Step 1: Create the Database Schema​

import Database from "better-sqlite3";

const db = new Database("archive.db");
db.pragma("journal_mode = WAL");

db.exec(`
  CREATE TABLE IF NOT EXISTS chats (
    id           TEXT PRIMARY KEY,
    name         TEXT,
    unread_count INTEGER NOT NULL DEFAULT 0
  );
  CREATE TABLE IF NOT EXISTS messages (
    chat      TEXT    NOT NULL,
    id        TEXT    NOT NULL,
    sender    TEXT    NOT NULL,
    from_me   INTEGER NOT NULL,
    timestamp INTEGER NOT NULL,
    push_name TEXT,
    text      TEXT,
    raw       TEXT    NOT NULL,
    source    TEXT    NOT NULL,
    PRIMARY KEY (chat, id)
  );
  CREATE INDEX IF NOT EXISTS messages_chat_ts ON messages (chat, timestamp);
`);

The primary key is (chat, id) because message IDs are only guaranteed to be unique within a chat. The same message can arrive more than once, for example in two history chunks or in a history chunk and as a live event. An upsert on this key stores it once, as long as both copies use the same chat JID. If WhatsApp addresses a chat by its LID in one place and by phone number in another, you get two rows (see LID JIDs below):

const upsertMessage = db.prepare(`
  INSERT INTO messages (chat, id, sender, from_me, timestamp, push_name, text, raw, source)
  VALUES (@chat, @id, @sender, @fromMe, @timestamp, @pushName, @text, @raw, @source)
  ON CONFLICT (chat, id) DO UPDATE SET
    text = COALESCE(excluded.text, messages.text),
    raw = excluded.raw,
    push_name = COALESCE(NULLIF(excluded.push_name, ''), messages.push_name)
`);

timestamp is in Unix seconds, the same value as info.timestamp.

Step 2: Extract Message Text​

Text can be in different fields depending on the message type:

function extractText(message: Record<string, unknown>): string | null {
  if (typeof message.conversation === "string") return message.conversation;

  const ext = message.extendedTextMessage as { text?: string } | undefined;
  if (ext?.text) return ext.text;

  for (const key of ["imageMessage", "videoMessage", "documentMessage"]) {
    const media = message[key] as { caption?: string } | undefined;
    if (media?.caption) return media.caption;
  }
  return null;
}
  • conversation holds plain text
  • extendedTextMessage.text holds replies, links, and mentions
  • imageMessage.caption, videoMessage.caption, and documentMessage.caption hold media captions

Save the full message as JSON in the raw column too. That way you can extract more fields later, like reactions, polls, or quoted replies (extendedTextMessage.contextInfo.stanzaID), without syncing again.

Step 3: Store History Sync Chunks​

Write each chunk in a single transaction. With thousands of messages per chunk, this is much faster than committing each row separately:

import type { HistorySyncConversation, MessageInfo } from "@whatsmeow-node/whatsmeow-node";

function saveMessage(
  info: MessageInfo,
  message: Record<string, unknown>,
  source: "history" | "live",
): void {
  upsertMessage.run({
    chat: info.chat,
    id: info.id,
    sender: info.sender,
    fromMe: info.isFromMe ? 1 : 0,
    timestamp: info.timestamp,
    pushName: info.pushName,
    text: extractText(message),
    raw: JSON.stringify(message),
    source,
  });
}

const saveChunk = db.transaction((conversations: HistorySyncConversation[]) => {
  let count = 0;
  for (const conv of conversations) {
    upsertChat.run({ id: conv.id, name: conv.name, unreadCount: conv.unreadCount });
    for (const { info, message } of conv.messages) {
      saveMessage(info, message, "history");
      count++;
    }
  }
  return count;
});

client.on("history_sync", ({ type, chunkOrder, progress, conversations }) => {
  const count = saveChunk(conversations);
  console.log(
    `[history] ${type} chunk #${chunkOrder}: ${conversations.length} chats, ` +
      `${count} messages (progress ${progress}%)`,
  );
});

upsertChat is defined in the complete example. It keeps the last non-empty chat name.

Step 4: Archive Live Messages​

New messages use the same table and the same saveMessage() function:

client.on("message", ({ info, message }) => {
  saveMessage(info, message, "live");
});

Unlike in a bot, you should not skip info.isFromMe here. Messages you send from your phone are part of the conversation too.

Edits, reactions, and deletions also arrive as live message events with their own IDs. An edit, for example, is a protocolMessage with type: "MESSAGE_EDIT" and key.ID pointing at the original message. This archiver stores them as separate rows with text = NULL. To apply edits, check for protocolMessage.editedMessage and update the row for protocolMessage.key.ID instead. (History sync already applies edits: an edited message arrives with the original ID and the edited content.)

Step 5: Request Older History On Demand​

The initial sync only includes recent history. To get older messages for a chat, ask your phone for messages before the oldest one you already have:

const oldestInChat = db.prepare(`
  SELECT id, chat, sender, from_me, timestamp
  FROM messages WHERE chat = ?
  ORDER BY timestamp ASC LIMIT 1
`);

async function requestOlderMessages(chat: string, count = 50): Promise<void> {
  const row = oldestInChat.get(chat) as
    | { id: string; chat: string; sender: string; from_me: number; timestamp: number }
    | undefined;
  if (!row) return;

  const oldest: MessageInfo = {
    id: row.id,
    chat: row.chat,
    sender: row.sender,
    isFromMe: row.from_me === 1,
    isGroup: row.chat.endsWith("@g.us"),
    timestamp: row.timestamp,
    pushName: "",
  };

  const request = await client.buildHistorySyncRequest(oldest, count);
  await client.sendPeerMessage(request);
}

buildHistorySyncRequest(info, count) builds a peer data request, and sendPeerMessage() sends it to your own phone. The reply does not come back as the return value. It arrives later as a history_sync event with type: "ON_DEMAND", and the handler from Step 3 stores it. Include isFromMe in the info object, because WhatsApp uses it to identify the oldest message.

Step 6: Pair From the Archiver​

WhatsApp pushes the initial history (INITIAL_BOOTSTRAP and RECENT chunks, plus other types such as PUSH_NAME) only once, right after a new device is paired. whatsmeow-node doesn't request a full sync, so expect recent months of history, not the whole account. Any process that is connected when the sync arrives consumes it: whatsmeow acknowledges each chunk and deletes it from WhatsApp's servers, even with no history_sync listener. If you pair with a separate script that stays connected, that history is gone.

Handle the QR code in the archiver itself so it is listening when the sync starts:

import qrcode from "qrcode-terminal";

client.on("qr", ({ code }) => {
  qrcode.generate(code, { small: true });
});

const { jid } = await client.init();
if (!jid) await client.getQRChannel();
await client.connect();

If you missed the initial sync, unlink the device on your phone (Settings → Linked Devices), delete session.db, and pair again.

Complete Example​

import {
  createClient,
  type HistorySyncConversation,
  type MessageInfo,
} from "@whatsmeow-node/whatsmeow-node";
import Database from "better-sqlite3";
import qrcode from "qrcode-terminal";

const client = createClient({ store: "session.db" });
const db = new Database("archive.db");
db.pragma("journal_mode = WAL");

db.exec(`
  CREATE TABLE IF NOT EXISTS chats (
    id           TEXT PRIMARY KEY,
    name         TEXT,
    unread_count INTEGER NOT NULL DEFAULT 0
  );
  CREATE TABLE IF NOT EXISTS messages (
    chat      TEXT    NOT NULL,
    id        TEXT    NOT NULL,
    sender    TEXT    NOT NULL,
    from_me   INTEGER NOT NULL,
    timestamp INTEGER NOT NULL,
    push_name TEXT,
    text      TEXT,
    raw       TEXT    NOT NULL,
    source    TEXT    NOT NULL,
    PRIMARY KEY (chat, id)
  );
  CREATE INDEX IF NOT EXISTS messages_chat_ts ON messages (chat, timestamp);
`);

const upsertChat = db.prepare(`
  INSERT INTO chats (id, name, unread_count)
  VALUES (@id, @name, @unreadCount)
  ON CONFLICT (id) DO UPDATE SET
    name = COALESCE(NULLIF(excluded.name, ''), chats.name),
    unread_count = excluded.unread_count
`);

const upsertMessage = db.prepare(`
  INSERT INTO messages (chat, id, sender, from_me, timestamp, push_name, text, raw, source)
  VALUES (@chat, @id, @sender, @fromMe, @timestamp, @pushName, @text, @raw, @source)
  ON CONFLICT (chat, id) DO UPDATE SET
    text = COALESCE(excluded.text, messages.text),
    raw = excluded.raw,
    push_name = COALESCE(NULLIF(excluded.push_name, ''), messages.push_name)
`);

function extractText(message: Record<string, unknown>): string | null {
  if (typeof message.conversation === "string") return message.conversation;

  const ext = message.extendedTextMessage as { text?: string } | undefined;
  if (ext?.text) return ext.text;

  for (const key of ["imageMessage", "videoMessage", "documentMessage"]) {
    const media = message[key] as { caption?: string } | undefined;
    if (media?.caption) return media.caption;
  }
  return null;
}

function saveMessage(
  info: MessageInfo,
  message: Record<string, unknown>,
  source: "history" | "live",
): void {
  upsertMessage.run({
    chat: info.chat,
    id: info.id,
    sender: info.sender,
    fromMe: info.isFromMe ? 1 : 0,
    timestamp: info.timestamp,
    pushName: info.pushName,
    text: extractText(message),
    raw: JSON.stringify(message),
    source,
  });
}

// One transaction per chunk: much faster than one commit per message
const saveChunk = db.transaction((conversations: HistorySyncConversation[]) => {
  let count = 0;
  for (const conv of conversations) {
    upsertChat.run({ id: conv.id, name: conv.name, unreadCount: conv.unreadCount });
    for (const { info, message } of conv.messages) {
      saveMessage(info, message, "history");
      count++;
    }
  }
  return count;
});

// Past messages: pushed after pairing, and in response to on-demand requests
client.on("history_sync", ({ type, chunkOrder, progress, conversations }) => {
  const count = saveChunk(conversations);
  console.log(
    `[history] ${type} chunk #${chunkOrder}: ${conversations.length} chats, ` +
      `${count} messages (progress ${progress}%)`,
  );
});

// New messages: archive them into the same table
client.on("message", ({ info, message }) => {
  saveMessage(info, message, "live");
});

// Ask the primary phone for older messages in one chat
const oldestInChat = db.prepare(`
  SELECT id, chat, sender, from_me, timestamp
  FROM messages WHERE chat = ?
  ORDER BY timestamp ASC LIMIT 1
`);

async function requestOlderMessages(chat: string, count = 50): Promise<void> {
  const row = oldestInChat.get(chat) as
    | { id: string; chat: string; sender: string; from_me: number; timestamp: number }
    | undefined;
  if (!row) {
    console.log(`No archived messages for ${chat} yet`);
    return;
  }

  const oldest: MessageInfo = {
    id: row.id,
    chat: row.chat,
    sender: row.sender,
    isFromMe: row.from_me === 1,
    isGroup: row.chat.endsWith("@g.us"),
    timestamp: row.timestamp,
    pushName: "",
  };

  const request = await client.buildHistorySyncRequest(oldest, count);
  await client.sendPeerMessage(request);
  // The answer arrives later as a history_sync event with type "ON_DEMAND"
}

// Pair from THIS process: the initial history is only pushed right after pairing
client.on("qr", ({ code }) => {
  qrcode.generate(code, { small: true });
});

async function main() {
  const { jid } = await client.init();
  if (jid) {
    console.log(`Resuming session for ${jid}`);
  } else {
    console.log("No session found — scan the QR code to pair");
    await client.getQRChannel();
  }
  await client.connect();
  console.log("Archiving messages to archive.db...");

  process.on("SIGINT", async () => {
    await client.disconnect();
    client.close();
    db.close();
    process.exit(0);
  });

  // Example: backfill a chat passed on the command line (needs a logged-in session)
  const backfillChat = process.argv[2];
  if (backfillChat && (await client.waitForConnection())) {
    await requestOlderMessages(backfillChat);
  }
}

main().catch(console.error);

Run it with npx tsx archive.ts. To backfill one chat, pass its JID: npx tsx archive.ts 5989XXXXXXXX@s.whatsapp.net.

Then query the archive with any SQLite tool:

SELECT datetime(timestamp, 'unixepoch') AS sent, push_name, text
FROM messages
WHERE chat = '5989XXXXXXXX@s.whatsapp.net'
ORDER BY timestamp;

Common Pitfalls​

History is only sent once, when you pair

The initial history sync happens only right after pairing. Run the archiver during pairing (Step 6). If you missed it, unlink the device, delete the session store, and pair again. On-demand requests can backfill specific chats later, but they need your phone to be online.

LID JIDs

Chat and sender IDs may be LIDs (123456789@lid) instead of phone-number JIDs (5989...@s.whatsapp.net), especially in history sync data and groups. The same person can appear under both forms. Store IDs as you receive them and don't assume every JID contains a phone number. This also means the same chat can end up under two chat values in the archive, so deduplication and requestOlderMessages() only work within one form. See JIDs, LIDs & Device IDs for details.

Large initial syncs

Accounts with years of chats can produce hundreds of chunks. Use one transaction per chunk, avoid slow work (like downloading media) inside the history_sync handler, and don't treat the first chunk as the complete history. progress is 0 for sync types that don't report it, so use it only for display.

Media is not downloaded

The archive stores the media message metadata (in raw), not the files. Media links from old messages often have expired. To keep files from new messages, download them when they arrive (How to Download Media).

Field naming

The message object uses proto JSON names, like stanzaID, mentionedJID, and fileSHA256 (not stanzaId). See Troubleshooting.

Store responsibly

A chat archive contains other people's private messages. Protect the database file with disk encryption and restricted file permissions, don't commit it to git, only archive accounts you are authorized to archive, and follow the privacy laws that apply to you (GDPR, LGPD, etc.), including deletion requests.

Related Guides

Download MediaDownload Media

Download Media

Save incoming images, videos, audio, and documents to disk.

Build a BotBuild a Bot

Build a Bot

Create a WhatsApp bot from scratch — receive messages, handle commands, send replies.

Pair WhatsAppPair WhatsApp

Pair WhatsApp

Link a WhatsApp account via QR code or phone number code.

Forward MessagesForward Messages

Forward Messages

Relay messages between chats — text, media, and any message type.

JIDs, LIDs & Device IDsJIDs, LIDs & Device IDs

JIDs, LIDs & Device IDs

Decode JIDs, @lid senders and device suffixes — normalize, compare and build JIDs safely.
